Power Monitoring
• AC mains voltage monitoring;
• DC power supply
• Local WEB server for control and monitoring;
• SNMP-V2 protocol for monitoring;
• Compatible with monitoring systems such as Zabbix, Grafana, LibreNMS, The Dude, among others
• 3 inputs for dry contact sensors;
• 1 input for digital sensor;
• Temperature monitoring (integrated sensor);
• Relative humidity monitoring (integrated sensor);
• Programmable dry contact output for up to 5 A;
• Possibility of sending alerts and status via email and Telegram, in conjunction with SNMP manager software;
• Easy installation.
| Input Characteristics | |
| Input Power Supply Voltage | 10 – 60 VDC |
| Input Connection | – RJ45 PoE 802.3af Connector – Terminal Block Connector for up to 1.5mm2 wire |
| Sensor Characteristics | |
| AC Voltage Sensor | – 60 – 270 VAC – Terminal Block Connector for wire up to 1.5mm2 |
| DC Voltage Sensor | – 10 – 60 VDC – Terminal Block Connector for wire up to 1.5mm2 (same connector as the power input) |
| Temperature Sensor | -20°C to 65°C, Integrated Sensor |
| Humidity Sensor | 0% to 100% RH, Integrated Sensor |
| Dry Contact Inputs | 0 – 60 VDC |
| Digital Input | 0 – 60 VDC (Voltage above 5 VDC refers to logic level 1) |
| Relay | Terminal block connector for wire up to 1.5mm2 |
| Management Interface | |
| Ethernet | 10/100 Mbps |
| Supported Protocols | TCP/IP – SNMP V2 |
| Firmware Updates | Remote Update Management Interface |
| Relay Output | Voltage, temperature, humidity, dry contact inputs, digital input alarms |
| Monitoring | – C voltage, DC voltage, temperature, humidity, dry contact inputs, digital input, automation relay status measurement. – Allows customization of the name of each sensor, making it easier to identify connected devices. |
| Commands | Allows remote On/Off relay command sending. |
| Scheduling | Allows configuring up to 10 scheduling for relay activation, which can be programmed with time and day of the week accuracy |
| Manually Restore Factory Settings | The command is executed through a button located on the front panel. When pressed, it is possible to restore network settings |
| General Specifications | |
| AC Inputto Earth Isolation | 1000 VAC |
| DC Inputto Earth Isolation | 1000 VAC |
| Relay Contacts to Earth Isolation | 1000 VAC |
| Operating Temperature | -10°C to 60°C |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Device Power On Indicator (Green LED) | Device Power On |
| Relay Activation Indicator (Green LED) | Relay Activated |
| MTBF (Mean Time Between Failures) | 120,000 hours |
| Installation Mode | Rack or Panel Mounting |
| Dimensions (H x W x D)/ Weight | 34 x 110 x 113 mm / 0.297 kg |
